Korad KA6005P Benchtop Power Supply (Safety Terminals)

Korad KA6005P Benchtop Power Supply (Safety Terminals)

Artno.: KR1-260057
GTIN: 4251459248413
Manufacturers: Korad

Programmable Benchtop Power Supply, 1 channel (60V/5A), 300W, 10mV/1mA resolution, USB / RS232 interface

Variant: 239 €KA6005P (Screw Terminals) Out of stock

239 €KA6005P (Safety Terminals)

239,00 €

incl. 19% VAT

(200,84 € excl. VAT)

On stock (short supply)
Delivery time: 1 - 3 business days (DE - int. shipments may differ)

Configure + Buy

Measuring Leads

Hirschmann Measuring Lead Kit 2.5mm² 1m: Measuring lead kit
11,50 € Item details

Your configuration

incl. 19% VAT

(200,84 € excl. VAT)

KORAD introduces the KA series, a line of digital control and programmable regulated DC power supplies boasting industrial-grade performance. These power supplies feature comprehensive digital control, encoder-driven voltage and current adjustment, and rapid recall capabilities. They can be configured for overvoltage and overcurrent protection and come equipped with an intelligent temperature-controlled fan. Above all, the meticulous circuit design and tidy internal construction ensure the stability and reliability of the machine. The product range includes compact and portable single DC power supplies, as well as dual DC power supplies with a voltage range of 30V up to 100V and a current range of 2A up to 10A.

Models	KA3005	KA3010	KA6005
Voltage Range	0 - 30 V	0 - 30 V	0 - 60 V
Current Range	0 - 5 A	0 - 10 A	0 - 5 A
Load Regulation	≤ 0.01 % + 2 mV	≤ 0.01 % + 3 mV	≤ 0.01 % + 2 mV
Load Regulation	≤ 0.1 % + 10 mA	≤ 0.1 % + 20 mA	≤ 0.1 % + 10 mA
Line Regulation	≤ 0.01 % + 3 mV	≤ 0.01 % + 3 mV	≤ 0.01 % + 3 mV
Line Regulation	≤ 0.1 % + 3 mA	≤ 0.1 % + 3 mA	≤ 0.1 % + 3 mA
Setup Resolution	10 mV	10 mV	10 mV
Setup Resolution	1 mA	1 mA	1 mA
Setup Accuracy (25°C ± 5°C)	≤ 0.5 % + 20 mV	≤ 0.5 % + 20 mV	≤ 0.5 % + 30 mV
Setup Accuracy (25°C ± 5°C)	≤ 0.5 % + 10 mA	≤ 0.5 % + 20 mA	≤ 0.5 % + 5 mA
Ripple(20 - 20M)	≤ 2mVrms	≤ 2mVrms	≤ 1mVrms
Ripple(20 - 20M)	≤ 3mArms	≤ 5mArms	≤ 3mArms
Temp. Coefficient	≤ 150 ppm	≤ 150 ppm	≤ 150 ppm
Read Back Resolution	10 mV	10 mV	10 mV
Read Back Resolution	1 mA	1 mA	1 mA
Read Back Temp. Coefficient	≤ 150 ppm	≤ 150 ppm	≤ 150 ppm
Reaction Time	≤ 100 mS	≤ 100 mS	≤ 100 mS

Variations & Editions

Variatiants
Variant	P	P+
Programable	Yes
Interfaces	USB/RS232
Editions
Housing Color Front/Case	Grey/Grey	Grey/Black
Display:	single color LED Display(red)	two color LED Display(green/red)
Terminals
Terminal	(Sc) Screw Terminals	(Sc) Screw Terminals or (Sa) Safety Terminals
