Bambu Lab TPU 85A Filament on Spool

Artno.: BL5-851305-P
Manufacturers: Bambu Lab

Bambu Lab TPU 85A is an especially soft and highly flexible TPU filament for elastic, impact-absorbing and wear-resistant 3D printed parts. With its Shore hardness of 85A, it is ideal for protective cases, soft cushioning, dampers, flexible toys, grip zones and functional elastomer components.

Variant

from

38,32 €

incl. 19% VAT

(40,25 € excl. VAT)

plus

From	Unit Price
2	43,11 €*
4	40,72 €*
10	38,32 €*

50+ On stock

Please select a model.

BAMBU LAB TPU 85A FILAMENT

Bambu Lab TPU 85A

Very flexible TPU filament with Shore hardness 85A for soft, elastic and impact-absorbing 3D printed parts – ideal for protective cases, soft cushioning, dampers, flexible toys, grip zones and functional elastomer components.

The softest TPU in the Bambu Lab filament lineup

Bambu Lab TPU 85A is designed for especially flexible, elastic and impact-absorbing parts. Compared to TPU 90A or TPU 95A HF, TPU 85A is softer and more deformable. This makes it ideal for parts that need to bend, compress, absorb impact or serve as a soft contact surface.

Important: Very flexible feeding and dry filament

TPU 85A is very soft and moisture-sensitive. For clean results, dry the filament before printing, keep it as dry as possible during printing and feed it through a suitable TPU setup or dry filament box. Standard AMS and AMS lite are not suitable for soft TPU filaments; within the AMS series, TPU printing is intended for AMS HT using its dedicated TPU outlet.

Shore 85A

Very flexible

Impact absorbing

Print dry

Highlights

Maximum flexibility

Shore 85A creates very soft, elastic and highly deformable printed parts.

Excellent impact absorption

Ideal for parts that need to absorb shocks, vibration or repeated deformation.

High elongation

With very high elongation at break, TPU 85A is especially suitable for elastic functional parts.

Soft contact surfaces

Perfect for cushioning, protective elements, grips, flexible toys and soft damping parts.

Technical Data

Material	TPU – Thermoplastic Polyurethane
Product Line	Bambu Lab TPU 85A
Shore Hardness	85A
Diameter	1.75 mm
Net Filament Weight	1 kg
Nozzle Temperature	200–250 °C
Build Plate Temperature	30–35 °C
Build Surface	Smooth PEI Plate or Textured PEI Plate; glue recommended
Print Speed	Below 200 mm/s recommended
Chamber Temperature	25–45 °C
Nozzle Recommendation	0.6 mm or 0.8 mm recommended
AMS Compatibility	Standard AMS and AMS lite not recommended; AMS HT possible with dedicated TPU outlet
Drying	70 °C for 8 hours in a forced-air / drying oven or 90 °C for 16 hours on the printer heatbed
Storage / Printing Humidity	Preferably below 20% RH; store sealed with desiccant
Density	1.18 g/cm³
Melting Temperature	177 °C
Water Absorption	0.67% at 25 °C / 55% RH
Breaking Elongation	>700% in X-Y direction; >350% in Z direction
Special Properties	Very soft, highly flexible, impact absorbing, wear resistant, elastic and ideal for soft functional TPU parts

Typical Applications

Protective Cases

Soft Cushioning

Dampers

Flexible Toys

Grip Zones

Elastomer Components

More Information from Bambu Lab

Visit the official Bambu Lab product page for more information about TPU 85A, print recommendations, compatibility and technical material data.

View Bambu Lab TPU 85A →

Printing Recommendation

TPU 85A is very soft and sensitive to moisture. Wet material can cause stringing, bubbling, inconsistent surfaces and reduced layer adhesion. The elasticity of a part strongly depends on wall loops, infill density, part geometry and print orientation. For flexible functional parts, Shore hardness, wall thickness, infill, moisture condition and load requirements should be tested for the specific application.
