Bambu Lab PA6-GF Filament on Spool 72600 Blue

Bambu Lab PA6-GF Filament on Spool 72600 Blue

Artno.: BL5-372600
GTIN: 6975337036975
Manufacturers: Bambu Lab

Glass Fiber Reinforced PA6 (Nylon 6), Built to last, dimensional stability, exceptional thermal properties, chemical resistance, smooth surface and more colors, diameter: 1.75 mm +/- 0.03 mm, AMS Compatible

Variant: 62,90 €72102 White

62,90 €72103 Gray

62,90 €72104 Black

62,90 €72200 Orange

62,90 €72400 Yellow

62,90 €72500 Lime

62,90 €72600 Blue

62,90 €72800 Brown

62,90 €

incl. 19% VAT

(52,86 € excl. VAT)

On stock (short supply)
Delivery time: 1 - 3 business days (DE - int. shipments may differ)

Description
Product Reviews

Bambu PA6-GF, also known as Nylon 6 with Glass Fiber, stands at the forefront of high-performance engineering plastics. Engineered to deliver exceptional strength, durability, dimensional stability. The PA6-GF is also more cost effective when compared to other top tier engineering filaments.

Key features

Built to last
Dimensional stability
Exceptional thermal properties
Chemical resistance
Smooth surface and more colors

PA6-GF Hex Code Table

Color	Hex Code	Display
White	#EAEAE4
Yellow	#FFCE00
Lime	#C5ED48
Blue	#75AED8
Orange	#FF4800
Brown	#5B492F
Gray	#353533
Black	#000000

Accessory Compatibility

	Recommended	Not Recommended
Build Plate	Engineering Plate, High Temperature Plate or Textured PEI Plate	Cool Plate
Hotend	Hardened Steel 0.4mm / 0.6mm (recommended) / 0.8 mm	Hotend with Stainless Steel Nozzle (all size) Hotend with Hardened Steel Nozzle (0.2 mm)
Glue	Bambu Glue Stick	Bambu Liquid Glue
AMS & AMS lite	AMS & AMS lite	/

Printing Tips

Bambu PA6-GF needs proper drying before printing: recommended drying temperature is 80 ℃ for 8 to 12 hours in a blast drying oven, or 90 to 100 ℃ for 10 to 12 hours on the heat bed. (Do not exceed 100 ℃ because the spool may deform or even melt).
To prevent the filament from absorbing moisture, it is recommended to use an airtight storage container with desiccant during printing.
To minimize warping, avoid printing large-sized high infill density models. Use enclosed printers and ensure the build plate is properly applied with glue for better print adhesion before printing.
For better print results, please refer to additional resources.

Post-processing Tips

We recommend removing the support structures within 2 hours after printing to prevent them from sticking after absorbing moisture. If sticking occurs, dry the model to ease the removal.
Placing the printed part in a convection oven set between 80 to 130 ℃ for 5 to 12 hours can further enhance the strength and rigidity of the print. Note: The effectiveness of this process depends on the structure, size, and conditions of the printed model. Some models may warp or deform after annealing.

Model Overview

	PA6-GF	PA6-CF	PAHT-CF
Composition	PA6, glass fiber	PA6, carbon fiber	PA12 and other long-chain PA, carbon fiber
AMS Compatibility	YES	NO	YES
Dry Out Before Use	Required	Required	Required
Printing Speed	< 130 mm/s	< 100 mm/s	< 100 mm/s
Printer Type	Enclosure	Enclosure	Enclosure
Toughness (Impact Strength - XY, dry state)	27.2 kJ/m²	40.3 kJ/m²	57.5 kJ/m²
Toughness (Impact Strength - XY, wet state)	55.8 kJ/m²	57.2 kJ/m²	62.3 kJ/m²
Strength (Bending Strength - XY, dry state)	120 MPa	151 MPa	125 MPa
Strength (Bending Strength - XY, wet state)	71 MPa	95 MPa	115 MPa
Layer Strength (Bending Strength - Z, dry state)	51 MPa	80 MPa	61 MPa
Layer Strength (Bending Strength - Z, wet state)	33 MPa	45 MPa	49 MPa
Stiffness (Bending Modulus - XY, dry state)	3670 MPa	5460 MPa	4230 MPa
Stiffness (Bending Modulus - XY, wet state)	2120 MPa	3560 MPa	3640 MPa
Layer Adhesion (Impact Strength - Z, dry state)	4.1 kJ/m²	15.5 kJ/m²	13.3 kJ/m²
Heat Resistance (HDT, 0.45 MPa, Dry State)	182 ℃	186 ℃	194 ℃
Saturated Water Absorption Rate/% (25 ℃, 55% RH)	2.56	2.35	0.88

Recommended Printing Settings for PA6-GF
Drying Settings (Blast Drying Oven)	80 ℃, 8 - 12 h
Printing and Keeping, Container's Humidity	<20% RH (Sealed, with Desiccant)
Nozzle Temperature	260 - 290 ℃
Bed Temperature (with Glue)	80 - 100 ℃
Printing Speed	< 130 mm/s
Physical Properties
Density	1.09 g/cm³
Vicat Softening Temperature	212 ℃
Heat Deflection Temperature	186 ℃
Melting Temperature	223 ℃
Melt Index	6.8 ± 0.6 g/10 min
Mechanical Properties
Tensile Strength	102 ± 7 MPa
Breaking Elongation Rate	5.8 ± 1.6 %
Bending Modulus	5460 ± 280 MPa
Bending Strength	151 ± 8 MPa
Impact Strength	40.3 ± 2.5 kJ/m²

Extended Specifications

Package Contents

Filament x 1 & Desiccant x 1
Package x 1

Features

Built to Last

Bambu PA6-GF is exceptionally strong and durable due to reinforced glass fibers, making it the perfect choice for prints that need to withstand heavy use and resist bending or breaking. Note: The printed part achieves better toughness after exposure to moisture.

Dimensional Stability

Exceptional Thermal Properties

PA6-GF boasts a high heat deflection temperature and superior dimensional stability, enabling it to retain its mechanical properties even under elevated temperatures. This makes it ideal for demanding industrial and automotive applications.

Chemical Resistance

PA6-GF offers excellent resistance to chemicals, oils, and many kinds of solvents, ensuring long-term performance in challenging environments.

Smooth Surface and More Colors

Bambu PA6-GF filaments are compatible with the Bambu AMS system, ready to print in multi-color. The special surface texture also blurs the layer lines, providing a smooth surface quality.

More Features

Shipping weight:	1,40 kg
