Dobot MG400 Industrial Robot
The Dobot MG400 is a compact 4-axis industrial robot designed for simple automation, education, laboratory applications, and rapid prototyping. With a 440 mm reach, 0.5 kg payload capacity, and high ±0.05 mm repeatability, it provides an affordable and user-friendly solution for automating repetitive tasks in space-constrained environments.
Featuring an ultra-compact footprint smaller than a standard A4 sheet of paper, the MG400 can be easily integrated into workstations, laboratories, classrooms, and production cells. Its intuitive programming environment enables users with little or no robotics experience to quickly deploy automation projects.
Key Features
Compact 4-axis industrial robot
440 mm working reach
0.5 kg payload capacity (up to 0.75 kg at reduced performance)
±0.05 mm repeatability
Maximum joint speed of 300°/s
Footprint smaller than an A4 sheet for space-saving installations
Intuitive Teaching & Playback programming
Graphical programming environment for beginners and professionals
Integrated Ethernet, USB, TCP/IP and Modbus TCP communication
Fast deployment and easy operation
Suitable for educational, laboratory and industrial applications
Ideal Applications
Small-part assembly
Pick-and-place automation
Laboratory automation
Electronics manufacturing
Testing and inspection processes
Educational robotics training
Research and development projects
Rapid prototyping and proof-of-concept systems
Easy Programming and Operation
The MG400 was developed with usability as a primary focus. Users can program the robot through intuitive Teaching & Playback functions or utilize graphical programming tools to create automation workflows without extensive coding knowledge.
Its user-friendly software ecosystem allows quick commissioning and enables companies, schools, and research institutions to implement robotic automation with minimal training requirements.
Compact Automation Solution
With its lightweight design and small installation footprint, the Dobot MG400 is particularly well suited for workspaces where traditional industrial robots would be too large or complex. It offers a practical entry point into industrial automation while maintaining professional precision and reliability.
Technical Specifications
Robot Type |
4-Axis Industrial Robot |
Reach |
440 mm |
Payload Capacity |
0.5 kg (up to 0.75 kg) |
Repeatability |
±0.05 mm |
Maximum Joint Speed |
300°/s |
Robot Weight |
8 kg |
Operating Temperature |
0°C to 40°C |
Tool I/O |
2 Digital Inputs / 2 Digital Outputs |
Control Box I/O |
16 Digital Inputs / 16 Digital Outputs |
Communication |
Ethernet, USB, TCP/IP, Modbus TCP |
Power Consumption |
150 W |
The Dobot MG400 combines industrial-grade precision, compact dimensions, and beginner-friendly operation, making it an ideal solution for education, laboratory automation, prototyping, and light industrial applications.
