Arducam B0151 OV5647 NoIR Camera Board with Motorized IR Cut Filter M12x0.5 Mount LS1820 Lens for Raspberry Pi 4/3B+/3

Arducam B0151 OV5647 NoIR Camera Board with Motorized IR Cut Filter M12x0.5 Mount LS1820 Lens for Raspberry Pi 4/3B+/3

Artnr.: AC2-201510
HAN: B0151
Hersteller: Arducam

Arducam OV5647 NoIR Camera Board with Motorized IR Cut Filter M12x0.5 Mount LS1820 Lens for Raspberry Pi 4/3B+/3

39,90 €

inkl. 19% MwSt.

(33,53 € exkl. MwSt.)

zzgl.

bestellbar
Lieferzeit: ca. 3 Monate (DE - Ausland abweichend)

Beschreibung
Kundenrezensionen

The Pi NoIR is a Raspberry Pi camera module with no Infrared filter for night time and low light photography using an Infrared light. Useful for wildlife research, science projects, night time security or making artistic photo's.

The Raspberry Pi camera module has been used for many things such as a security camera, for time lapse photography and even sent high up into the atmosphere on a weather balloon.

With the wide range of project Raspberry Pi's are being used for, some users were finding that the camera was no good when it was being used in low light with an Infrared light source. Unfortunately for them the Raspberry Pi camera module has a Infrared filter built in which makes it unusable for their project. In response we come up with a camera module just for these type of projects called the Pi NoIR camera. It is the same as the standard camera module but without an IR filter.

Without the Infrared filter the camera can be used for night time photography, night time security or for any project where the scene will be lit by an IR light. Without a filter the camera sensor can see short wavelength IR light around 800nm which is the IR wavelengths not generated with heat but just beyond the visible red light in the spectrum.

Features:

Raspberry Pi HD Camera
High-Definition video camera ffor Raspberry Pi 4B, Pi 3B+, Pi 3B, Pi 2, Model A/B/B+.
Omnivision 5647 sensor in a fixed-focus module with replaceable Lense
Lens holder: M12x0.5 or CS Mount
5MPixel sensor
Still picture resolution: 2592 x 1944
Max video resolution: 1080p
Max frame rate: 30fps
Size: 36 x 36 mm
Connection by flat ribbon cable to 15-pin MIPI Camera Serial Interface (CSI) connector S5 on Raspberry Pi computer board
IR Sensitive: onboard Motorized IR cut filter, support both visible and night vision

Package Including:

1pcs OV5647 NoIR Camera Board /w Motorized IR Cut Filter M12x0.5 Mount Lens LS1820 for Raspberry Pi
1pcs 15cm 15pin FPC cable
NOTE:Raspberry Pi NOT INCLUDED

Additional Resources:

Sensor Datasheet – OmniVision OV5647
Arducam Documentation – Arducam Cameras for Raspberry Pi
Blog – Arducam 5MP OV5647 IR Cut Pi Camera
Lens Options – Arducam M12 Mount Lens Kit, Arducam Low Distortion M12 Mount Lens Kit
