The official Pi HQ camera is only available in one model. It doesn't come with a lens and it is also not easy for the users to find a case. To solve these pain points, Arducam released this complete camera bundle, an IMX477 camera board with a 6mm CS lens, a customized metal enclosure, a tripod stand and a set extension adapter.
Features:
- Get Clearer Images: This camera adopts 1/2.3" 12.3 Megapixel IMX477 sensor for sharp image, max. still resolution 4056(H) x 3040(V).
- No Hassle: No more wasting time looking for the CS lens and camera case. It includes A 1/2.3" 6mm focal length CS lens, and an industrial metal enclosure mounted on the camera board, the bundle also comes with a mini tripod stand and a set HDMI extension adapter.
- More Lanes: The Arducam high quality camera module has a 4-lane MIPI CSI-2 interface, more than the official one, makes it possible to get more data through.
- Support More Platforms: It supports all Raspberry Pi camera models. Pi 4, Pi 3/3B+/3A+, CM3/3+, Pi Zero, and more. For Nvidia Jetson Nano and Xavier NX, you can search for B0249 / B0250 to get the Jetson camera bundle. For PC /laptop, you could purchase the HQ UVC camera module B0280 (with 6mm CS Mount Lens) or B0288 (with Varifocal C Mount Lens) directly.
Ordering in bulk? Or having questions about this camera? Talk to us!
Specifications
- Sensor: IMX477
- Optical Format: 1/2.3" (diagonal 7.857mm)
- Resolution: 4056(H) x 3040(V) 12.3MP
- Pixel Size: 1.55um x 1.55um
- IR Sensitivity: Visible light
- Interface: 4-lane MIPI CSI-2
- Default Lens Mount: CS-Mount
- Video Modes on Raspberry Pi: 1080p30, 720p60 and 640 × 480p60/90
-
- Format: 1/2.3 inch
- Focal Length: 6mm
- Aperture (F): Max. F1.2
- Field of View (FOV): 65° (H)
- Mount: CS-Mount
- Back Focal Length: 7.53mm
- MOD: 0.2m
- Dimension: F30×31mm
Package Includes
-
1 pcs complete 12.3MP IMX477 color camera mounted in a metal enclosure
-
1 pcs 1/2.3 inch 6mm focal length CS-mount lens
-
1 pcs HDMI-CSI camera adapter board with 60mm/2.36inch 15 pin camera cable
-
1 pcs 1m high-speed HDMI cable
-
1 pcs mini tripod stand
-
1 pcs 73mm/2.9inch 15 pin to 22 pin camera cable for pi zero&w
-
2 sets M2.5 nylon standoffs, screws and nuts
Documentation:
